Dongfeng Cummins Open Type 30KW Generator Set

  • Official guide price: 33200 Rise
  • Engine model: 4BT3.9-G1
  • Fuel consumption: 212 /KW.h
  • Decibel of noise: 105 dB/1m
  • *Advanced design and excellent manufacturing to adapt to harsh working conditions high intensity heavy load operation ability.
  • *The integrated design of cylinder block cylinder head and other parts "one multi-function" reduces the number of connecting parts. The parts are 40% less than other similar engines and the failure rate is greatly reduced.
  • *优异的动力性 最大输出功率可达500Kw 最大输出扭矩2990N.m,保证各种使用状态下的动力充沛。
  • *The internal purification scheme can meet the needs of hospitals schools and other places with more stringent emission requirements.
  • Product Detail

    Product parameters

  • Pre:Dongfeng Cummins Open Type 24KW Generator Set
  • Next:Dongfeng Cummins Open Type 40KW Generator Set

  • Generator set


    Length(mm)     1650 Engine brand     Dongfeng Cummins
    Width(mm)     1388 Engine model     4BT3.9-G1
    Height(mm)     830 conventional power(KW)     36
    Total weight(kg)     1020 Reserve power(KW)     40
    Generator set model     VGF-DKKJ-30 Bore / stroke(mm)     102*120
    Rated power(KW)     30 Number of cylinders(piece)     4
    Actual power(KW)     28.5 Cylinder arrangement     In-line
    Full load fuel consumption(L)     4.8 Air intake and exhaust mode     Pressure boost
    Operational duration(Hour)     72 Speed control mode     Mechanics
    Overhaul period(Hour)     3000 Rated fuel consumption(g/KW.h)     212
    Maintenance period(Hour)     500
    Life expectancy(Year)     20
    Noise(db)     105
    Starting mode     Manual key start
    Stop mode     Manually pull the valve for shutdown
    Battery matching     60A*2
    Fuel tank(L)     60
    Protection function
    Data display mode     Mechanical pointer instrument display
    Reference price(RMB)     33200
